A faster way to compute signed 64-bit floor division by constants

The missing chapter of Hacker's Delight

27 October 2026

What is signed integer floor division?
Signed integer floor division is where you do a/b and get a result that rounds towards −∞,
whereas standard (“truncated”) signed division rounds towards 0.
As stated in Hacker's Delight: “floor division more often gives the result you want”.

This article is about floor division where the divisor is known at compile time.

Despite the usefulness of this function, the world of integer floor division is in shambles:

• Mainstream compilers and many languages do not provide it natively (eg. C/C++/Go/Swift).
• Languages and software libraries that do implement it seem to almost never use the fastest algorithms.
• At least one highly prominent software library had a buggy overflowing implementation for over 4 years! (detailed later)
• Typical online searches and LLM prompts usually only surface the slow algorithms
• And finally, Hacker's Delight (basically the bible on low-level computer math), has almost nothing to say about it!

This blog post aims to not only shine light on the fast algorithms, but will also introduce a new fast approach which, with ideal compilation:

• On ARM, benches 10–20% faster throughput than existing algorithms for most 64-bit divisors (occasionally tied), with equal or better latency
• On x86, benches:
  • ~5-10% faster throughput for around 80% of positive 64-bit divisors (60% of negative divisors)
  • slower in the remaining x86 cases, and usually worse (but competitive) latency

The benchmark section has a detailed overview showing per-divisor results over many platforms, for throughput and latency.

It works in all bit-widths, and may find use on some 32-bit or SIMD applications, but the biggest benefit is in 64-bit.
It also can be used for faster positive-modulus, and faster "Euclidean" division (differs to floor division for negative divisors).

Floor division can be much faster than you probably realise.
Below is a snapshot throughput benchmark for division by 86400 (the number of seconds in one day), the kind of performance you can expect using most languages' built-in methods, vs fast alternatives outlined in this blog.

Note: in the bar chart: lower = faster.

*Rust provides "div_euclid", which matches floor-div for positive divisors.
See the benchmark section for a deeper comparison across over 40 divisors.

Starting with Truncated (Standard) Division Deep link

If you haven't bit twiddled much, the step u64(ts) >> 63 might seem odd. This is just moving the highest-bit down to the bottom. Since the top bit is the sign-bit on 2's complement computers, this leaves a 1 for negative numbers and a 0 for positive numbers.

Aside on Uncooperative Divisors Deep link

Btw, if you're new to all this, you might think: "Great! I now understand how signed division works at the compiler level!"
Sorry to burst the bubble, but here's what the same thing looks like for 64-bit division by 100:

The main takeaway here is that regular division is usually the cost of around 1 multiplication + 2-3 cycles.

Fixing the Bug Deep link

Okay, back to div 86400; you get bitten by the bug, and decide to patch it. It's pretty clear that the bug can occur when x < 0, but not always. If it's negative and divisible by 86400, it still works.
So therefore, it needs adjusting when rem < 0, like so:

C++

1. const int64_t div = x / 86400;

2. const int64_t rem = x % 86400;

3. return div - (rem < 0);

But you think to yourself, surely there must be a faster way? Computing the modulus is almost as expensive as the division itself, and it gets thrown away after the bump in our theoretical use-case.

The 2nd example below is perhaps the first simplification that may come to mind, but it's actually slower! You can visit the GodBolt link to see that it produces more assembly lines...

C++ (attractive, but slower)GodBolt (this and above)

1. const int64_t div = x / 86400;

2. return div - (div * 86400 > x);

Okay, screw this unintuitive nonsense, let's Google "fast floor division in c++", and get an AI summary like this (cached PDF export).

This AI summary is very misleading, as it falsely claims "Here are the fastest, branchless methods for each scenario.", before presenting a constant floor division routine that is no better than our attempt here, despite faster ways being known for 30 years+ (although it handles negative divisors at least).

What Hacker's Delight Has to Say About It Deep link

Hacker's Delight, 2nd Edition, has a section listed in the table of contents: "10–12 Applicability to Modulus and Floor Division". That sounds promising!

It comes immediately after dozens of awesome pages with fancy tricks for other types of division (signed, unsigned etc.).

“ It might seem that turning modulus or floor division by a constant into multiplication would be simpler, in that the “add 1 if the dividend is negative” step could be omitted. This is not the case. The methods given above do not apply in any obvious way to modulus and floor division. Perhaps something could be worked out; it might involve altering the multiplier m slightly, depending upon the sign of the dividend. ”— Henry S. Warren, Jr.,   Hacker's Delight, 2nd Edition

That's the whole section...

Normally, it might be copyright infringement to duplicate an entire section from a book, but in this case it's so short I think I'm covered by fair use.

Although Warren doesn't offer any solutions, the section highlighted in yellow perfectly predicts the new approach I'll introduce later.

Faster Techniques Deep link

At this point, you would be forgiven in thinking this can't be optimised any further; maybe it can't for runtime divisors (I have not investigated, since I've focused mainly on compile-time). Looking further, the first Google Search result: the archaeological remains of the once bustling Stack Overflow. The title looks promising: Fast floor of a signed integer division in C / C++ .

The post is from 2017, and has 6 answers. The OP and the top five up-voted results all use variations of the above technique.

By my benchmarks this gives a neat improvement, it runs around 50% greater throughput on most devices.

What does ufoguy get for adding this?
No thanks, no up-vote, just a comment pointing out that this does not account for negative numbers.
A fair caveat. If we're going to make a fast general purpose lib, it might as well be flexible.

Luckily, the general case was solved at least as far back as the 90s.
It is documented clearly on page 6 of Division by Invariant Integers using Multiplication - Granlund, Montgomery, 1994.

The Positive Divisor XOR Trick Deep link

The division in the previous section was, at best, a mul-shift plus 5-6 cycles.
Why so many?

1. One for x < 0 (or x > 0).
2. One to add that to the numerator.
3. One to subtract that from the result.
4. Two or three for the division itself (remember earlier we showed division is a mul-shift + 2-3 cycles?)

Luckily for us, Granlund and Montgomery have another trick up their sleeve, but it's only specified for positive divisors:

The big saving here comes from the fact that a is not only unsigned, but also only has a range of 0..2^63-1 (half of the usual range). This means that a mul-shift will work in all cases, even for uncooperative divisors.

I've found one library in the wild that uses this technique, PyPy , but it falls back to div/mod algorithm for negative divisors.

If you're counting along, this looks like a mul-shift plus 3 cycles, a clear improvement.
On ARM it could theoretically be a mul-shift plus 2 cycles, as the right-shifts can fuse with the XORs, but in practice on the machines I've tested, these fused operations don't result in the speed gain that raw cycle-counting would suggest.

Robison's Multiply Add Technique Deep link

On ARM devices, this compiles to a single fused "multiply-accumulate" operation, followed by right-shift. Even on ARM32, it can use the smlal operation to multiply, add the constant, and obtain the upper 32-bit result, without ever needing any 64-bit emulation.

Of course, x86-64 devices can run this fine: mul, add, shift.
32-bit x86 is where it becomes less clean (but not terrible). On this platform, the addition is performed on the lower 32-bit result, followed by adc to the upper 32-bit result (adds the "carry flag", which holds a "1" or "0" depending on whether the lower register overflowed or not).

So, what's the problem with this formula? Well, there's two problems...

Floor Div 101 (Robison)See GodBolt Given: x — Signed 32-bit integer

1. i64 A = 2721563435

2. i32 B = 0x511B0000  // 1360723968

3. return (i64(x) * A + B) >> 38;

Problem #1: It often requires a wider multiply.
To the right is how things change for division by 101.
There's a big difference here, see if you can spot it...

Notice that A is no longer i32 but i64?
This is an instance of this formula's uncooperative divisor; a case where the number of bits required in the multiplier is just one-too-many.

• You might notice that A is still between 2³¹ and 2³², so why does it need a 64-bit type?
  Well, if this number were represented as i32 the upper bit would be 1, causing it to wrap-around to -1,573,403,861.
• You might further notice that if you write it as u32, the code still runs right, does that make it 32-bit native?
  Unfortunately no, I have deceived myself several times into thinking this kind of thing over time. It will still run as a 64-bit multiplication on ARM and x86, as they do not have a built in i32 * u32 ➜ i64 operation (nor do they have i64 * u64 ➜ i128 etc).

Problem #2: Wider multiplication gets clunky at 64-bit
In the previous examples we talked of using wider types. This doesn't really work in 64-bit, you can use a type of "128-bit" in code, but it will be "emulated" using pairs of 64-bit registers. The below is how the Robison formula works out for our usecase 86400:

You can visit the Godbolt link to see that this compiles fairly reasonably on x86, the main hindrance is the "add back": it's only a couple of operations on x86 (adc), but on ARM64 it's a double-whammy: there's two multiplication operations (mul and smulh).
This is because ARM64 requires a separate multiplication for each high and low 64-bit half-result.

The "add back" is needed for the same reason as noted in the “Aside on Uncooperative Divisors” earlier.

These "issues" aren't terrible, this is still a really fast floor division function. It just leaves more left on the table to optimise.

Note: in case you haven't realised yet, problem #1 and #2 are really the same.

There's a second way to write the same math, which spells out the carry by hand instead of leaving it to a 128-bit addition. An example is in the code block below.

In theory the compiler should emit equivalent assembly for either form; in practice the two shapes don't always compile the same, so it's useful to know both and swap in whichever your compiler handles better. The ideal output for the carry form is an add followed by a carry-consuming instruction (adc on x86, cmp + cinc on ARM64); the failure mode is a longer dependent chain on the critical path.

Floor Div 86400 (Robison) - "Add Back v2"See GodBolt Given: x — Signed 64-bit integer

1. i64  A = -4454547087429121353  // 2^80 / 86400 + 1 - 2^64

2. u64  B = 0x6117 << 48

3. i128 w = i128(x) * A  // Compute high-64 and low-64

4. u64  lo = u64(w)

5. i64  hi = i64(w >> 64) + x  // "add back" x

6. hi += (lo + B < lo)  // Carry from adding B to the low half

7. return hi >> 16

You can see the assembly for each approach on Godbolt here . GCC and Clang each produce tighter assembly for a different variant.
Since compilers treat these differently, both of them are included in the benchmarks for a more thorough comparison.

There's one more compiler quirk worth knowing about: when the multiplier A is a compile-time constant, clang will rewrite smulh(x, A) into umulh(x, A) + (x >> 63) * A, adding two instructions to every divide. A one-line inline-asm barrier that holds A in a register but hides its value from the optimiser is enough to shut this down — the constant still gets materialised once and hoisted out of the loop.

Nonetheless, where widening is possible, Robison's approach is great. This includes 32-bit floor division on ARM (even SIMD in this case).
It's ideal in all 8-bit scenarios, as all mainstream chips seem to require doubling width anyway for 8-bit multiplication.
It can also lead to some really cool special cases, such as:
fast_i8_floordiv_51 => (x * 5 + 2) >> 8
That function above can compile to just 2 assembly operations on x86! (LEA + arithmetic right-shift).

Finally, on to the new stuff Deep link

“These computer division algorithms are all just fancy mul-shifts at the end of the day.”
— Sun Tzu, The Art of War

Let's try to go down to bare metal, and see what we get if we do a plain mul-shift for division by 3.
No corrections, no nothing.

We choose 3, because it's the first non-trivial divisor (power-of-2 divisors are solved with a simple arithmetic right-shift).

The round-up multiplier gives a perfect sequence of sets-of-3 in the positive direction, and just one discontinuity in the negative direction with a set of -1 and -2 (everything negative is shifted right).

Anyway, if we use the round-down multiplier:

...we get the opposite result: the negative direction has a perfect sequence, and the positive direction has a broken quadruple set at 0-3 (everything positive is shifted right):

It turns out that 3 is a very flexible divisor, and for now you'll just need to take my word for it that in 64-bit, the neat half of each continues over the entire signed-64 bit range.
So the answer here is simple, we can just use a different multiplier for positives and negatives:

Now it's clean in both directions.

I've tried other 64-bit floor division algorithms for throughput, this one’s the best.

This is the ideal scenario, as the value M + (x >> 63) can be computed very cleanly. It involves no extra constant materialisation, no flag-to-register conversion, and on ARM64 chips it can be computed with a single shift-add assembly operation (add x0, x1, x2, asr #63).

GCC compiles this well, however in my benchmark loops Clang seems to bungle it a little. One can force better compilation on Clang in C++ by writing asm("" : "+r"(m));after the 2nd line, which stops the compiler from proving that m >= 0, which fixes the bungled optimisation.
Note: similar asm-hacks were required in the benchmark to get the best out of the Robison algorithm.

However, it's not the only way we can implement it. Two other options are available in the case of floor division by 3:

1. Use a round-up value of M,      and bump x for every value that is less than -1; or –
2. Use a round-down value of M, and bump x for every value in this range: 0 <= x < MAX_INT64 (a positive "saturating increment").

In the first case, we don't want to bump x = -1 because that will give an incorrect result of y = 0.
In the second case, we don't want to bump x = MAX_INT64 because that will overflow.
The reason we don't need to bumpx = MAX_INT64 (x = 2^63-1), is because (2^63-1) FLOOR_DIV d = (2^63) FLOOR_DIV d for any divisor dthat is not a power‑of‑2. These would only differ if 2^63 was divisible d, but it's clearly not since the prime factors of 2^63 are all just 2.
That identity is about exact division though, and the round-down multiplier is only approximate. If d divided 2^63-1, then skipping the bump would leave INT_MAX an exact multiple nudged slightly downward, and the result would be one too low. Those divisors are safe to ignore here only because the INT_MIN check (see Implementation) already rules them out at register-sized shifts.
This is the same reason a saturating increment is used in fast unsigned division of certain divisors (see ridiculousfish / libdivide).

It is fortunate that the two bounds for the latter approach can be implemented with a sign cast and single comparison. Both constants of -1 and 0x7FFFFFFFFFFFFFFF can also materialise in a single ARM assembly operation due to their repeating bit-patterns. In a tight loop, such constants would typically be materialised once outside of the loop.

Anyway, why talk about all this when the case of 3 was already solved?
Well it turns out that not all divisors are as flexible as 3.

All non-power-of-2 integer divisors come in two overlapping sets:

• those that can do Round-Up + Negative Bump; and –
• those that can do Round-Down + Positive Bump.

Divisors that can use both, are eligible for the Sign-Selected-Multiplier version.

Below you can see the first 100 divisors, and what method is selected. The pattern is quite chaotic, but easily computed at compile-time:

• “>>” denotes a trivial power-of-2 divisor
• “↑” round-up multiplier (negative bump)
• “↓” round-down multiplier (positive bump)
• “↑↓” sign-selected multiplier
• “↑*” and “↓*”: selected-multiplier works at a larger shift-size, but a specific rounding direction gives a register-sized shift (disabled for 8-bit).

The number under this denotes the shift-size, highlighted when it's a clean register-sized shift.

Whoops, the above widget lets you select "Negative" divisors, but I haven't talked about those yet...

Negative Divisors

Everything we have gone through works the same with negative divisors. We just have to be careful with signs, comparisons etc.
I'll refer to "round down" multipliers as those that round towards zero, and "round up" multipliers as those that round away from zero.

Fast Floor-Modulus and Euclidean Division

Floor modulus flows naturally from floor-division, and is a "positive modulus" function for positive divisors:

For certain divisors of the form $2^N-2^K$, I have a faster alternative that uses an add-shift-mask:

See the day-of-week article and time-of-day article for more details about this identity.

Euclidean division is the same as floor division for positive divisors.
For negative divisors, we can use the following identity (except at INT_MIN) which results in just one extra cycle for the subsequent negation (the first negation for the floor_div call is performed at compile-time).
The second runtime negation can in some cases be absorbed for "free" in subsequent operations, such as in obtaining Euclidean modulus:

Implementation

The simplicity of these functions above comes with extra compile-time complexity to solve the constants and variant, but it builds fast.

Basically it boils down to iteratively testing the worst-case scenario for both the round-up and round-down versions, starting with an ideal register-sized shift $W$. A solution is valid if it passes the worst-case numerator. Eg:

• for the round-up version, the largest numerator equal to $(D-1)modD$
• for the round-down version, the largest numerator equal to $0modD$

One detail matters here: the worst case for round-down is INT_MIN, and its product must not land exactly on an integer, or the result comes out one too high. That happens exactly when $D$ divides $2^{W-1}-1$ (in 64-bit: 7, 49, 73, 127, 337, 511, …).
For these divisors, writing $r=2^{S}modD$, $r=2^{S-(W-1)}$ at every register-sized shift, so round-down never passes and they are forced to round-up. (For negative divisors it's the other way around: round-up is the one that can land on an integer, for |D| dividing $2^{W-1}+1$, in 64-bit: 3, 9, 19, 27, 43, 57, …)

If solutions are found for both, then the sign-selected variant will also work, at a shift equal to the greater of the two solutions found.

My benchmarking (in 64-bit) suggests it is fastest to choose sign-selected when possible, except for some rare cases:

1. If round-down has a perfect 64-bit shift, but sign-selected does not, then round-down variant is faster everywhere.
2. If round-up has a perfect 64-bit shift, but sign-selected does not, then round-up variant is faster on ARM, but either equal or slower on x86.

On x86, round-up loses to sign-selected because its bias is a signed compare (x < -1). The result of a signed compare isn't left in the carry flag, so the compiler needs cmp → setl → add, one more instruction than round-down's cmp → adc, and that extra cycle cancels the saving from skipping the extra shift. On an Intel Mac I got equal performance between them, but on an AMD processor I saw the sign-selected version run faster. As such, my benchmarks and the reference implementation alter the choice here for x86.

These exceptions noted above (register-sized shifts) are somewhat common for small divisors, eg 5, 6, 9, 14 etc., however, over the full set of possible 64-bit divisors, it is a vanishingly small set.
The Venn diagram below shows the distribution of divisors, and this tiny set is noted in the lower right.

The problem of finding out which variant works for a given divisor boils down to the same problem as finding an unsigned divisor in a bit-width one-size smaller than usual, i.e.: 63, 31, 15, or 7; and others have written at length about this, hence I'd like to keep this section brief. The more important thing is the proof that the negative side works given the positive side is well studied (see Annexure A - Proof).

“When it comes to signed floor division, there are no cooperative divisors, or uncooperative divisors, just these united divisors.”
— Barack Obama, 2004 Democratic National Convention

Never Roll Your Own Fast Floor Division Algorithm Deep link

Well, by all means feel free to, but make sure to test it thoroughly, otherwise you might end up with a bug like in Google's TensorFlow.

If you're interested, you can view the source to try to figure out yourself what was wrong with it.

The buggy implementation of this floordiv function was present in the 1.0 release in Feb 2017.
This bug then remained in place for over 4 years until it was fixed in May 2021 .

No shade to the author, this is fiddly to get right. The main reason I wanted to highlight this was to show how easy it is to get wrong, even in a mature, heavily-reviewed codebase. This is all the more reason for languages and standard libraries to provide this function outright.

Benchmarks Deep link

Tests used for validating the functions in this article can be found in the testcase code: https://github.com/benjoffe/fast-floordiv .

The same repository is used for benchmarking, and you can run them yourself like this:

git clone https://github.com/benjoffe/fast-floordiv.git
cd fast-floordiv
cmake -B build -DCMAKE_BUILD_TYPE=Release
cmake --build build -j
./build/bin/div_bench -batch=8
./build/bin/div_bench -latency

The benchmarks run for all non-power-of-2 divisors between -2^4 and 2^5, as well as a handful of cherry-picked larger positive divisors (100, 360, 86400, 10⁵, 10⁷, 86400000, 10⁸). The reason is detailed in the x86 section below.

In the charts, the x-axis represents these various divisors, and the y-axis is the nanoseconds-per-division (lower = faster).

All results were obtained by running the benchmark with -repeat=10 and recording the median results.
The -batch=8 command runs each divisor 8 times before loading the next entry from memory. This ensures that the processor is not bottlenecked by memory access.
Latency results use the same command but replace the batch flag with -latency. This mode feeds the result of each computation into the next division, so there is no parallelisation.

To avoid making this page huge, I have grouped the benchmarks by chip type (ARM, x86) and benchmark type (throughput, latency).

ARM Throughput

On Clang, the New algorithm has highest throughput for all divisors, and occasionally tied with gm-v2.
The fastest alternatives are gm-v2 for positive divisors and Robison for negatives.
MSVC appears to produce sub-optimal assembly for negative divisors for a few of the algorithms.

ARM Latency

We get similar results for latency, with the New algorithm performing best, or tied-best.

x86 Throughput

x86 processors are where we have more of a mixed bag.
For throughput, the fastest algorithm seems to fluctuate between Robison and the New algorithm.
Sometimes gm-v2 comes out tied as fastest (eg. divisors 6 and 9).
You can see now why some larger divisors were cherry-picked: they demonstrate that some useful divisors perform well in the New algorithm.

The cases where the New algorithm does not win follow a clear pattern:

• Positive: 7, 11, 13, 22, 26, 29. These are all round-up-only divisors (~20% of all 64-bit positive divisors)
• Negative: -3, -5, -9, -11, -13, -15. These are divisors that don't use sign-selected where Robison is cooperative (~40% of all 64-bit negative divisors)

x86 Latency

Latency benchmarks are where we start to see a clearer winner on x86.
While there was a lot of fluctuation before, now Robison wins for nearly all divisors.
Rarely, the New algorithm seems to win on both throughput and latency, as seen for 14, -7, -14 (round-down with 64-bit shift).

Finally, I note that if you need the modulus, the gap between "traditional" and the faster algorithms will close, but they still remain faster. I would like to actually finish this blog post one day so I'll skip these benchmarks.

Which algorithm should I use? Deep link

The points below may be worth considering for anyone looking to make a fast floor division library or language/compiler feature:

• I would generally recommend Robison for 8, 16 and 32-bit.
• If you're not interested in absolutely maximising the performance, Robison is also very good for 64-bit, and it will keep your code simplest to have only one implementation.
• If you are interested in optimisation, using the New algorithm in all ARM 64-bit cases will be ideal, as it's better (or tied) on all metrics there.
• For x86 64-bit, there's a more complicated choice:
  • Continuing to use the New algorithm here is a reasonable choice, as it wins on throughput most of the time, and it keeps the tests reproducible across platforms.
  • Using Robison for x86 is worth considering, given it still wins fairly often, and has better latency.
  • Or, a highly optimised library targeting maximum throughput might choose to use New for x86 only in the cases where the throughput appeared to win, namely sign-selected and round-down for positive divisors, and a similar selection process for negative divisors. This is a fairly aggressive level of optimisation though, so whether it's worth it is up to you.
• I haven't tested on 32-bit processors, but I believe that 32-bit ARM will remain strong with Robison due to its multiply-accumulate instruction (the paper itself was motivated by the existence of this type of instruction), and 32-bit x86 might warrant a similar decision as 64-bit x86 (although this is probably not a very important target these days).

Two further points worth noting are:

• Robison did not seem very easy for me to optimise in C++ across different platforms for all 64-bit divisors, hence why the benchmarks have two different implementations. Direct assembly, or some kind of per-platform logic might be required to get it perfect.
• The performance benefit of auto-vectorised code using the New algorithm on ARM SVE2 SIMD chips might be higher than shown in the benchmarks, as that SIMD instruction set has a built-in instruction that obtains the high 64-bit result of a 64-bit product without widening. In these cases, Robison might end up widening the lanes or causing the compiler to not auto-vectorise. Unfortunately I don't have ready access to such a computer, so I haven't had a chance to try this myself. SIMD optimisation in general is an exercise left to the reader.

If you found this interesting, you might also like to see the below two recent blog posts.
They both discuss a new trick for faster positive-modulus for divisors of the form 2^A - 2^B (eg. 12, 24, 60 etc.), which might be worth including in any library that does both floor division and positive-modulus.

You should follow me on X to get notified when I publish more optimisation articles.

Revision history:

• 25 October 2026 - Soft release draft
• 27 October 2026 - First release

Annexure A - Proof Deep link

Positive divisor, non-negative $x$.
For $x\ge 0$, $x$ is just an unsigned $(W-1)$-bit number, so the unsigned results (Granlund–Montgomery, ridiculousfish) apply directly with $N=W-1$. Either the round-up multiplier $M$ works directly, or the round-down multiplier $M^{\prime }$ works with an increment. At least one of the two always does, using an $N$-bit multiplier, at a shift no larger than:

Writing $q=\lfloor n/D\rfloor$ for an unsigned $N$-bit input $n$, both variants land strictly between $q$ and $q+1$ whenever $n>0$:

These inequalities are strict (not $\le$), and this is a requirement rather than a free fact. That $D$ isn't a power of 2 only tells us neither multiplier is exactly $2^S/D$. For round-up the strictness then follows from the bound. For round-down, the product at $n+1=2^N$ lands exactly on $q$ when $D\mid 2^N-1$, since for those divisors $2^S=2^N\cdot r$ at every register-sized shift. The solver rejects round-down for them, which forces them to round-up.

In simple terms, these mul-shifts slowly "drift" away from the true ratio. Apart from at $x=0$, the non-rounded terms are never an integer (the check above ensures this).
The reason to point this out is that we will use the below identity which relies on that fact:

$$\lfloor -y\rfloor =-1-\lfloor y\rfloor \text{for non-integer}y$$.

Negative $x$.
Let $u:=\sim x=-1-x$. Bitwise NOT maps the negatives one-to-one onto $0\le u\le 2^N-1$ — exactly the range $n$ ranges over above — and also satisfies:

Combined with the standard floor/negation fact ($\lfloor -y\rfloor =-1-\lfloor y\rfloor$ for non-integer $y$), each case of the bump follows:

• Round-up, $x\le -2$. Here $1\le u\le 2^N-1$ — squarely in the strict range above — and $(x+1)\cdot M=-u\cdot M$, so:
  $$\lfloor \frac{(x+1)M}{2^S}\rfloor =\lfloor \frac{-uM}{2^S}\rfloor =-1-\lfloor \frac{uM}{2^S}\rfloor =-1-\lfloor \frac{u}{D}\rfloor =\lfloor \frac{x}{D}\rfloor$$
• Round-up, $x=-1$. This value is not covered by the case above (it has $u=0$, outside the strict range), which is exactly why the bump skips it and uses the plain, unbumped $x\cdot M=-M$ instead. Since $D\ge 3$: $M=\lceil 2^S/D\rceil \le 2^S/3+1<2^S$, so $-M/2^S$ lies strictly inside $(-1,0)$, giving $\lfloor -M/2^S\rfloor =-1=\lfloor -1/D\rfloor$.
• Round-down, $x\le -1$. Here $0\le u\le 2^N-1$ — the full unsigned domain, no exclusion needed, since the increment variant's bound above only ever needs $u+1\ge 1$, true for every $u\ge 0$. Since $x\cdot M^{\prime }=-(u+1)\cdot M^{\prime }$:
  $$\lfloor \frac{x{M}^{\prime }}{2^S}\rfloor =\lfloor \frac{-(u+1)M^{\prime }}{2^S}\rfloor =-1-\lfloor \frac{(u+1)M^{\prime }}{2^S}\rfloor =-1-\lfloor \frac{u}{D}\rfloor =\lfloor \frac{x}{D}\rfloor$$
  At $x=\text{INT\_MIN}$ this needs the increment at $u=2^N-1$ without saturating, and needs $(u+1)M^{\prime }/2^S=2^N{M}^{\prime }/2^S$ not to be a whole number for the negation identity to apply. Given the unsigned round-down bound, $2^S\ge 2^N\cdot r$, it is a whole number only when $2^S=2^N\cdot r$ and $D\mid 2^N-1$, in which case the product is exactly $(2^N-1)/D$, so those divisors cannot use round-down. The same exclusion is what makes skipping the increment at INT_MAX safe in the saturating variant.

So whichever rounding works for unsigned $(W-1)$-bit division also works across the whole signed $W$-bit range, with the same multiplier and shift.

Sign-selected. This uses round-up's unbumped half and round-down's unbumped half, so it works at any shift where both roundings work. A rounding that works at some shift keeps working at larger shifts, so it's enough that each works somewhere within the $N$-bit multiplier limit.

Negative divisors.

So this is the positive-divisor problem applied to $-x$. The one difference is the range: $-x$ runs from $-(2^{W-1}-1)$ up to $2^{W-1}$. The non-negative side holds one value more than $W-1$ bits allow (the image of INT_MIN), and the negative side holds one value less. That extra value is where round-up can land on an integer, which it does for $|D|\mid 2^N+1$, so those divisors can't use round-up. The missing value on the other side is the one that ruled out round-down for $D\mid 2^N-1$, so for negative divisors that exclusion goes away. That's why the reference implementation adjusts the bounds based on the divisor's sign.
